Description

AOS Cine35 EVO Frame kit

Frame Specs:

Frame style: CINEWHOOP 3.5 INCH PROPSProp size: Supports 3.5″ PropsWeight:  gramsFC mounting:  20x20mm(M2) and 25.5x 25.5mm(M2) and 30.5x 30.5mm()Front and rear mounting: 20x20mm(M2) and 25.5x 25.5mm(M2)Camera mounting: Carbon fiber platesCamera options: DJI FPV or 19x19mm CamerasCamera spacing: 19x19mm Motor mounting: 19x19mm up to 12x12mm(2004 or 2104 recommended)

STANDOFF COLOR: BLACK

Carbon fiber parts included:

4x – 4.0mm Arms2x – 0.5mm Camera Spacer2x – 1.0mm Camera Spacer1x – 2.0mm Bottom plate w/M2 pressnuts1x – 2.0mm Top plate w/M2 pressnuts1x – 2.0mm Main Plate2x – 2.0mm Camera plates
Hardware included:3x M2 23mm Standoffs(Textured)11x M2 25mm Standoffs(Textured)9x M3 25mm Standoffs(Textured)21x M2 6mm Cap Head Screws5x M2 8mm BH Screws9x M3 6mm BH Screws9x M3 12mm BH Screws2x Soft Camera Mounts
