DIATONE MAMBA TOKA 2203.5 1650KV RACING MOTOR

Description

Diatone Mamba Toka 2203.5-1650KV for your micro quads!

SPECIFICATIONS:

• Overall Dimension:Φ28.9×29.4mm
• prop mounting shaft diameter:5mm
• Installation hole position:16×16mm，M3
• Prop:  5inch
• Bearing：9*4*4
• Shaft Diameter:4.0mm
• Lead Wire Size：24AWG×190mm
• slots/poles:12N14P
• Magnet Wire: 240℃ Enameled Wire
• Stator Diamter：22mm
• Stator Height:3.5mm
• Rated Voltage:4~6S (16.8V~25.2V)
• Peak Current: 15.59A
• ldle Current：10V/0.3~1.0A
• Maximum Power: 380.8W
• Internal Resistance：232Ω

INCLUDES:

• 1 x Mamba Toka 2203.5 Brushless Motor
