Description
|
Xact Coreless 5300 Series High-Voltage Servos |
||||||
|
DIMENSION (L*W*H) |
HV5301 : 35*15*31mm MD5301H : 35.5*15*25.3mm |
|||||
|
WEIGHT |
HV5301 : 41g MD5301H : 38.3g |
|||||
|
HORN SPLINE |
Φ6 25T |
|||||
|
STALL CURRENT |
HV5301 : [email protected] / [email protected] / [email protected] MD5301H : [email protected] / [email protected] / [email protected] |
|||||
|
OPERATING VOLTAGE RANGE |
4.8-8.4V |
|||||
|
REFLASH RATE |
1520us/333Hz | 760us/700Hz |
|||||
|
PERFORMANCE |
TORQUE|SPEED @6.0V |
TORQUE|SPEED @7.0V |
TORQUE|SPEED @8.4V |
|||
|
HV5301 |
4.4 kgf.cm 61.1 Oz-in |
0.11 sec/60° |
5.2 kgf.cm 72.2 Oz-in |
0.09 sec/60° |
6.1 kgf.cm 84.7 Oz-in |
0.08 sec/60° |
|
PERFORMANCE |
TORQUE|SPEED @6.0V |
TORQUE|SPEED @7.4V |
TORQUE|SPEED @8.4V |
|||
|
MD5301H |
20kgf.cm 277.7Oz-in |
0.1 sec/60° |
23kgf.cm 319.4Oz-in |
0.08sec/60° |
27 kgf.cm 374.9 Oz-in |
0.06sec/60° |
