Hobbywing Xerun XR10 Pro ESC — Legacy Edition (2026)
The Hobbywing Xerun XR10 Pro Legacy Edition brings proven competition-grade performance to the 2026 lineup at an exceptional value. Built on the established XR10 Pro platform that has earned its reputation across 1/10 touring car, buggy, drift, F1, and rally racing, this ESC delivers the precise, responsive power management that competitive racers demand. Nine pre-configured profiles cover the full range of 1/10 racing disciplines right out of the box, while variable PWM and brake frequency regulation lets drivers fine-tune driving and braking forces to match their exact style and track conditions. Hobbywing’s innovative softening function adds another layer of power delivery tuning for improved efficiency and smoother throttle response. A dedicated programming port powers an external cooling fan independently and serves as the connection point for an LCD Program Box Pro or OTA Programmer for full configuration and firmware updates. Running data can be monitored via the HW LINK app using an optional OTA Bluetooth module, and a comprehensive protection suite — covering low-voltage cutoff, thermal protection, fail-safe, and reverse polarity — keeps the ESC and motor safeguarded through the hardest sessions.
- Nine select-to-use profiles covering all major 1/10 racing applications
- Variable PWM and brake frequency regulation for precise driving and braking force tuning
- Hobbywing Softening function for refined power delivery and driving efficiency
- Independent programming port powers external fan or connects to LCD Program Box Pro / OTA Programmer
- Data logging compatible with HW LINK app via optional OTA Bluetooth module
- Firmware upgradeable via Hobbywing LCD Program Box Pro or OTA Programmer (sold separately)
- Comprehensive protection: low-voltage cutoff, ESC and motor thermal, fail-safe, and reverse polarity
- Switch-mode BEC with adjustable 5–7.4V output and 5A continuous current
- BEC-powered cooling fan for stable, consistent thermal management
| Specification | Detail |
|---|---|
| Continuous / Peak Current | 150A / 1000A |
| Applications | 1/10 Touring Car & Buggy Racing, Drift, F1, Rally |
| Motor Limit — Touring Car | 4.5T and higher |
| Motor Limit — Buggy | 5.5T and higher |
| Motor Size | 3650 (540) 2-Pole |
| LiPo Cells | 2S LiPo (2S Only) |
| BEC Output | 5–7.4V Adjustable, 5A Continuous (Switch-Mode) |
| Cooling Fan | BEC-Powered |
| Programming Port | Independent |
| Reverse Polarity Protection | Yes |
| Dimensions | 37.7 x 37.0 x 33.2mm (with Fan & Fan Shroud) |
| Weight | 94.2g (with Wires) |
| Included | Qty |
|---|---|
| Hobbywing Xerun XR10 Pro ESC — Legacy Edition | 1 |
| Factory Decals and Accessories | 1 set |
