Description
Universal Compatibility: The LS-008D FPV Goggle supports an impressive range of frequency bands, including Band A, Band B, Band E, Band F, and Band R, ensuring compatibility with a wide variety of FPV setups and race events.
Built-in DVR and Auto Searching: With a built-in DVR and one-button auto searching feature, this FPV goggle allows you to easily record your flights and seamlessly find the best available channels without hassle, enhancing your FPV experience.
High-Quality Display and Low Latency: The 4.3-inch high-brightness IPS display with an 800×480 resolution offers a clear and immersive viewing experience. Combined with low latency real-time video return, you can enjoy smooth and responsive video transmission during your FPV flights.
Comfortable and Portable Design: Weighing just 300g and featuring a universal USB charging interface, the LS-008D is lightweight and easy to carry around. The 3.7v 2000mAh built-in battery ensures extended flight sessions, while the adjustable headband and comfortable foam padding provide a snug fit for prolonged use.
Band A – 5865 / 5845 / 5825 / 5805 / 5785 / 5765 / 5745 / 5725
Band B – 5733 / 5752 / 5771 / 5790 / 5809 / 5828 / 5847 / 5866
Band E – 5705 / 5685 / 5665 / 5645 / 5885 / 5905 / 5925 / 5945
Band F – 5840 / 5760 / 5780 / 5800 / 5820 / 5840 / 5860 / 5880
Band R – 5658 / 5695 / 5732 / 5769 / 5806 / 5843 / 5880 / 5917
Features:
- Built-in DVR with simple operation using SD card and on/off button
- Low power consumption
- Double antenna reception
- One-button auto searching
- 4.3″ high brightness display
- 800×480 resolution
- 40-channel RaceBand receiver
- Built-in 3.7v battery for up to 5 hours of use
- Universal USB charging interface
- Real-time video return with low latency
- Supports external video signal input
- Supports audio signal output for headphone use
Specifications:
- Model: LS-008D
- Color: White
- Screen size: 4.3 inch IPS
- Resolution: 800x480px
- Display ratio: 16:9
- View angle: Full view
- Brightness: 500cd/m^2
- Antenna Connector: RP-SMA
- Delay: <20ms
- Lens: 2.8x Fresnel Lens
- DVR type: VGA/D1/HD
- Frame rate: 30 frames
- Compress format: MJPEG
- Record file format: AVI
- Power adapter: DC5V/2A (USB)
- Power consumption (normal/record): 400mA / 620mA
- Weight: 300g
- Dimensions: 155x144x113mm
Package Contents:
- 1x LS-008D 5.8GHz FPV Video Goggles
- 1x Carrying Case
- 2x RP-SMA Antennas
- 1x Charging Cable
