MC8 Multifunction 2-8S Cell Checker

Description

Introducing the MC8 Multifunction 2-8S Cell Checker – the ultimate tool for all your cell checking needs. With a large and clear display, you can easily monitor cell voltages and balance your packs. Plus, this versatile device allows you to check PWM/PPM/SBUS output, generate PWM output for servo and ESCS testing, and even charge your devices using LiPos (up to 20W PD) – all in one compact package!

Specifications

• LCD:  2″ IPS 320×240
• Dimensions: 68x50x15mm
• Weight: 50g

Checker

• Main Input port: XT60 7.0-35.0V
• Balance input: 0.5V-5.0V Lixx 2-8S
• Signal port input: <6.0V
• Balance current: MAX 60mA @2-8S
• Balance accuracy: <0.005V @ 4.2V
• USB-A output: [email protected] firmware upgrade
• USB-C output: 5.0V-12.0V @MAX 20W
• USB-C protocol: PD3.0 QC3.0 AFC SCP FCP

Measurer

• PWM: 500-2500us @20-400Hz
• PPM: 880-2200us*8CH @20-50Hz
• SBUS: 880-2200us*16CH @20-100Hz

 Output

• PWM: 1000-2000us @20-1000Hz
• PPM: 880-2200us*8CH @50Hz
• SBUS: 880-2200us*16CH @74Hz

Includes

• 1x Toolkit RC MC 8 Multi-Functional 2-8S Battery Checker
