RC4WD FF-030 Micro Electric Motor

Description

• Output Shaft Length: 0.20in / 5.1mm
• Rated Voltage: 7.4 V
• High Torque Magnet and Rotor
• Hardened Steel Gear
• Total Length: 1.12in / 28.5mm
• Output Shaft OD: 0.06in / 1.5mm
• Weight: 0.38oz / 11g
• Pinion Gear: 80P 10T
• Tuned for Rock Climbing and Scale Driving

Specifications

• High Torque Magnet and Rotor
• Tuned for Rock Climbing and Scale Driving
• Hardened Steel Gear
• Pinion Gear: 80P 10T
• Rated Voltage: 7.4 V
• Total Length: 1.12in / 28.5mm
• Output Shaft Length: 0.20in / 5.1mm
• Output Shaft OD: 0.06in / 1.5mm
• Weight: 0.38oz / 11g

Includes

• 1x FF-030 Micro Electric Motor
• 1x M2 x 10mm SHSC (Black)
• 1x M2 x 4mm SHSC (Black)

Note: Fits RC4WD 1/18 Gelande II RTR with D90 Body Set

Application

Rock Climbing and Scale Driving

Motor Type

Brushed

Product Length

1.12in / 28.5mm

Product Weight

0.38oz / 11g

RPM/Volt (Kv)

7032RPM at No Load

Shaft Diameter

0.06in / 1.5mm

Shaft Length

0.20in / 5.1mm

Tooth Count

10 Tooth
