Velotech Programming Card for Swallow and Etium ESCs

Description

This programming card simplifies the setup process of VeloTech Etium and Swallow ESC parameters by eliminating the need for manual transmitter adjustments. With this card, users can program the following settings (if supported by their VeloTech ESC):

(01) Aircraft Type:

1. Airplane
2. Helicopter – Factory Settings
3. Helicopter – RPM Signal Output

(02) Battery Type:

1. LiPo
2. NiMH & NiCd
3. LiFe

(03) Cutoff Voltage:

1. 3.2V
2. 3.0V
3. 2.8V
4. 2.0V
5. 1.8V

(04) Cutoff Mode:

1. Normal
2. Soft
3. Very Soft

(05) Start Mode:

1. Normal
2. Soft
3. Very Soft

(06) Brake Type:

1. Disabled
2. Soft
3. Hard

(07) Timing Advance:

1. 0
2. 5
3. 15
4. 20
5. 25

(08) BEC Voltage:

1. 5.3V
2. 6V
3. 7.4V
4. 8.2V

(09) PWM Rate:

1. 12KHz
2. 8KHz

(10) Recover Factory Settings:

1. Yes
2. No
